Description

In the use of interventional diagnosis or treatment surgery, the percutaneous puncture is used to insert the vascular system, provide the channels for angiographic catheters, guide catheters, balloon dilating catheters, and other similar instruments to enter arteries and veins, and provide channels for normal saline and/or diagnostic contrast agents.

Features

01

The unique hemostatic valve design keeps good hemostasis and smooth operation; The connector is transparent, which makes it easier to observe the blood return.
02

The sheath surface is coated with hydrophilic coating, which has low friction, excellent trafficability, and reduces the incidence of complications.
03

The sheath and expansion tube is wedge-shaped and perfectly fitted, reducing puncture resistance and intraoperative vascular injury.
04

The sheath body is reinforced with metal wire and designed with a three-layer structure, which has good bending resistance and support.
05

The design of the detachable hemostatic valve connector provides more user options.
06

The sheath tip is the radiopaque developing ring, with accurate positioning.
07

It is easier to identify with an internationally unified color identification number and digital code.
08

A wide selection of specifications and models, 4F-10F size, 40cm-110cm length, and the end S, A, B, and C bending types are optional, without fear of climbing mountains.

Specification

TYPE:S	order no.	14040451801	14040453501	14050451801	14050453801	14060453801	14070453801	14080453801	14090453801	14100453801
	Model	4F-45-18-S	4F-45-35-S	5F-45-18-S	5F-45-38-S	6F-45-38-S	7F-45-38-S	8F-45-38-S	9F-45-38-S	10F-45-38-S
	order no.	14040551801	14040553501	14050551801	14050553801	14060553801	14070553801	14080553801	14090553801	/
	Model	4F-55-18-S	4F-55-35-S	5F-55-18-S	5F-55-38-S	6F-55-38-S	7F-55-38-S	8F-55-38-S	9F-55-38-S	/
	order no.	14040701801	14040703501	14050701801	14050703801	14060703801	14070703801	14080703801	14090703801	/
	Model	4F-70-18-S	4F-70-35-S	5F-70-18-S	5F-70-38-S	6F-70-38-S	7F-70-38-S	8F-70-38-S	9F-70-38-S	/
	order no.	14040901801	14040903501	14050901801	14050903801	14060903801	14070903801	/	/	/
	Model	4F-90-18-S	4F-90-35-S	5F-90-18-S	5F-90-38-S	6F-90-38-S	7F-90-38-S	/	/	/
	order no.	14041101801	14041103501	14051101801	14051103801	14061103801	14071103801	/	/	/
	Model	4F-110-18-S	4F-110-35-S	5F-110-18-S	5F-110-38-S	6F-110-38-S	7F-110-38-S	/	/	/
TYPE:A	order no.	/	/	/	14050403802	14060403802	14070403802	14080403802	14090403802	14100403802
TYPE:A	Model	/	/	/	5F-40-38-A	6F-40-38-A	7F-40-38-A	8F-40-38-A	9F-40-38-A	10F-40-38-A
TYPE:B	order no.	/	/	14050451803	14050453803	14060453803	14070453803	14080453803	14090453803	14100453803
	Model	/	/	5F-45-18-B	5F-45-38-B	6F-45-38-B	7F-45-38-B	8F-45-38-B	9F-45-38-B	10F-45-38-B
	order no.	14040551803	14040553503	14050551803	14050553803	14060553803	14070553803	14080553803	/	/
	Model	4F-55-18-B	4F-55-35-B	5F-55-18-B	5F-55-38-B	6F-55-38-B	7F-55-38-B	8F-55-38-B	/	/
	order no.	14040701803	14040703503	14050701803	14050703803	14060703803	14070703803	14080703803	/	/
	Model	4F-70-18-B	4F-70-35-B	5F-70-18-B	5F-70-38-B	6F-70-38-B	7F-70-38-B	8F-70-38-B	/	/
	order no.	/	/	14050901803	14050903803	14060903803	/	/	/	/
	Model	/	/	5F-90-18-B	5F-90-38-B	6F-90-38-B	/	/	/	/
TYPE:C	order no.	/	/	14050551804	14050553804	14060553804	14070553804	/	/	/
TYPE:C	Model	/	/	5F-55-18-C	5F-55-38-C	6F-55-38-C	7F-55-38-C	/	/	/
